Flap Barrier Turnstile Gate Access Control Door QR Code Control for Office

Flap Barrier Turnstile Gate Access Control Door QR Code Control for Office

Flap barrier: Imagine a doorway that uses fins instead of a swinging door. That’s kind of like a flap barrier, but instead of swinging open, the fins rinse up to let one person pas through at a time. You see them a lot at places like train stations or office buildings. They help control the flow of people and make sure only authorized people enter. They often work with a security card or even facial recognition so only people with permission can get the fin to rise up and let them pass.

Features and Function of swing Barrier:

1. 304 stainless steel, Apperance design, generous, beautiful, humanized design. Appearance can be customized;.  2.High-performance integrated control panel, strong anti-interference ability, stability system, Drive module does not       heat heat, Low power consumption;3. Scour protection function; when the open signal is not received, arm will be locked after 5 degrees rotation;4.Automatic reset function: After turnstile opened, not pass within a specified period of time,5.Read the card with memory and without memory function: users can be set using the keyboard according to their needs;6.Audible alarm function: Including unlawful entry, trailing and anti pinch;7.6—10 pairs of infrared sensors to detect the trailing and anti pinch;8.Unique design, perfect control technology, beautiful and destinguised design, making products frequently favored by domestic and foreign high-end users.

Product Technical Parameters

Model Number	MR Y209
size	1200*130*980mm
Material	SS304 grade stainless steel
Thickness of material	body cabinet 1.0mm, top of cover 1.2mm
Arm material	Acrylic/Glass 10mm thickness
Channel width	≤1000mm
open gate signal input	Dry contact signals, 232 or 485 commands.
Unlocking time	0.2s
Speed of passage	≤35p/Min
Voltage input	220V, 50H; (support adjustable)
environmental temperature	-25°C~+70°C
working environment	Indoor/outdoor (under shade)
MCBF	≥5 million
weight	single core movement: 50KG / double core movement: 70KG
configuaration	one channel comes standard with 2 Astrometry air switches, 2 Meanwell switching power supplies, 2 motherboards, 2 super capacitors, and 6 pairs of infrared
Driving Motor	DC Servo motor or brushless motor: 24v/40w, 36v/200w, 24v/150w
Alarm	Illegal passage alarm, retrograde alarm, standard alarm, can be linked to the voice broadcasting, lights and other warnings, Mechanical anti-clamping, infrared anti-clamping and anti-clamping with current:
Advantages	The equipment has fault active feedback function, for gate failure, can actively upload fault code, realize the early warning, convenient maintenance Through the management computer to realize remote control door single pass open door, normally open, normally closed, fire control, return to normal and so on.

Special Functions

1. power failure open gate or power failure close gate is optional, default power failure open gate 6. Legal passage electronic booster pusher, illegal passage lock clutch.2. support memory mode, automatic reset, free to set the passage time, support the passage of the completion of the feedback, equipment can be set remotedly more than 10 kinds of flexible configuration of the gate mode;3. Equipment to support remote control of the pedestrian passage time settings, and real-time feedback settings;4. Equipment to support the passage of the completion of the feedback, fault active feedback function for the gate failure, can actively upload the fault code, to achieve early warning, easy maintenance;5. Realize early warning, convenient maintenance;6. Through the management computer to achieve remote control door single pass open door, multi-pass open door, normally open, normally closed, fire control, return to normal, etc.

Secondary development

tripod turnstile gates, 2w swing gates, wing gates, speed gates have a unified secondary development interface, a docking, can be connected to a variety of equipment; Can also provide the gate 485 development protocol, has been encapsulated industrial control machine docking gate secondary development agreement(can provide RS485 protocol, windows API, limux API

Optional Access Control Solutions:

The turnstile gate can work with RFID Card, QR code, Barcode, ESD Tester. Thermometer Recognition, Face recognition, Fingerprint, Password Recognition, and other attendance device solutions.

Occasion Application:

suitable for commercial buildings, schools, GYM fitness centers or clubs, subways, airports, metro stations, IT Centre, office, college, term parts, Supermarket, Railway stations, Library, Exhibition halls, government buildings, financial, industrial, University,  institutions, clubs, and other high-end places related to entrance access control solutions.
